A while back we rolled a routine Envoy upgrade to one of our customers' dedicated proxies. Same config, same traffic, and the CPU graphs stepped up by roughly a fifth. This is the kind of chart that earns you a calendar invite with no agenda, so we decided to get ahead of it and started digging in.
Bisecting versions pointed at Envoy v1.34, which is where Envoy switched its default HTTP/2 codec from nghttp2 to Google's oghttp2. We weren't the first to notice: users had been reporting 15–25% latency regressions since that release, and v1.37.0 eventually flipped the default back, with a comment in the source promising to try again "once performance aligns with nghttp2." That fixed our customer. It did not fix our curiosity. Why doesn't it align? What does an HTTP/2 codec even spend its time on?
This post is the investigation. There's a sequel coming where we make the fast codec faster still, but first things first.
The best of codecs, the worst of codecs
Envoy has two implementations of HTTP/2 behind a runtime flag, though nobody could say which was which without a flamegraph:
- nghttp2 - Tatsuhiro Tsujikawa's C library, the HTTP/2 workhorse since 2013 and Envoy's original codec. Lean C structs, caller-provided buffers.
- oghttp2 - Google's C++ codec from the QUICHE family, which shares code with the HTTP/3 stack. It became Envoy's default in v1.34, and that's when the regression reports started.
We benchmarked both on four microarchitectures (Intel Sapphire Rapids, AMD Zen 4, AWS Graviton4,
Google Axion). Setup, briefly: same-host loopback (h2load → Envoy → Go h2c backend, or Envoy
serving direct_response), every process pinned to disjoint physical cores, Envoy at
--concurrency 1, so RPS/core is a pure CPU-efficiency number.
The user reports reproduce almost exactly: nghttp2 beats oghttp2 by 15–25% RPS/core on header-heavy proxied traffic, on every host, and by 7–19% under heavy connection churn. So the regression is real, portable, and lives somewhere in the codec. Time to open the profiles.
If you build Envoy yourself, check your optimization flags. Envoy's .bazelrc does not
default to -c opt - a plain bazel build //source/exe:envoy-static produces a fastbuild (debug)
binary that looks completely functional and benchmarks 15–32× slower per core than the same
source at -c opt. Every number in this post is from -c opt builds. We found this out the
embarrassing way.
Where an HTTP/2 codec spends its day
The flamegraphs for both codecs are dominated by the same job: header decompression. Every HTTP/2 request that crosses a proxy arrives with its headers compressed, and the proxy has to undo that - twice per hop, decode and re-encode - before it can route anything. It's a few hundred bytes of work per request, which sounds like nothing until you multiply it out: tens of thousands of requests per second per core, a dozen-plus header fields each, so the per-field decode path runs a few hundred thousand times a second.
The compression scheme is HPACK (RFC 7541): two
mechanisms working together. The first is indexing: a fixed 61-entry static table covers
the universal headers (:method: GET is a single byte), and both sides maintain a synchronized
dynamic table of recently seen header fields - so the second time you send cookie: session=abc... it costs one or two bytes instead of the kilobyte it costs literally. The second
mechanism handles everything that can't be an index hit: literal strings are Huffman-coded.
First-time headers, unique values (request IDs, tokens, the cookie your ad vendor rotates on every
request), and most of what crosses a fresh connection goes through the Huffman path. A proxy at the
edge sees a lot of fresh connections and a lot of unique values, so this path is hot.
A two-minute tour of Huffman coding
In 1951, Robert Fano offered the students in his MIT information theory course a choice: sit the final exam, or write a term paper on a problem he supplied. One of the problems sounded almost too plain to be worth a grade - given a set of symbols and how often each one occurs, find the most efficient binary code for them. Fano didn't mention that he and Claude Shannon (yes, the Claude Shannon) had both attacked this exact problem and gotten only approximations. A graduate student named David Huffman picked the paper, struggled with it for months, and by his own account had just thrown his notes in the trash to start studying for the exam when the solution surfaced. Everyone before him had built codes from the top down, splitting the symbol set into halves. Huffman inverted it: start from the bottom - take the two rarest symbols, merge them into one, repeat until a single tree remains. Rare symbols end up deep in the tree with long codes; frequent symbols end up shallow with short ones. That term-paper construction is provably optimal.1 Seventy-five years later it sits inside JPEG, gzip, MP3 (for kids, this is like Spotify but without ads) - and every HTTP/2 header on the internet.
HPACK ships one fixed Huffman code for header text, its frequencies baked into the RFC from real header corpora captured a decade ago, so both ends of a connection always agree on it. Lowercase letters and digits sit near the top of the tree at 5–7 bits; rare bytes hang thirty levels deep. Typical header text comes out around 6 bits per byte. Now notice the property the tree structure gives you for free: no codeword can be the beginning of another, because symbols only live at the leaves. So the bit stream needs no delimiters at all. Read bits until they trace a path to a leaf - that's your symbol. Start again from the root. The stream carries its own boundaries, provided you start at the right place.
It also tells you where the cost lives. Encoding is table lookups and bit-appending. Decoding is that walk: left on 0, right on 1, emit at a leaf, jump back to the root - for HPACK's code, an average of ~6 dependent branch-and-load steps per output byte, which is a lot of machinery for one character of a cookie.
Here's the encoding half on a real header value - step through it character by character and watch the codes pack into bytes with no regard for byte boundaries:
nghttp2 does something much better, and has since 2014: it decodes with a precomputed finite-state machine. A decoder mid-stream can only be in finitely many states - one per internal node of the Huffman tree, and HPACK's canonical tree has exactly 256 of them, so the state fits in one byte. You can precompute, for every (state, next-n-bits) pair, where you end up and which symbols (if any) you emit along the way. Decoding becomes: take the next n bits, index a table, maybe write a byte, repeat. No bit-buffer, no branching on code lengths.
The machine below decodes a real header value under the real RFC 7541 code, reading two bits per lookup so the whole state table fits on screen. Step through it - the table and the tree are the same thing wearing different clothes:
nghttp2 runs exactly this machine with 4-bit chunks: two lookups per input byte into a table of 256 states × 16 nibble values - 16 KiB, which sits comfortably in L1 cache. Validity checking (HPACK requires padding to be all-ones, and an embedded end-of-string symbol is an error) folds into the same lookup. It's a genuinely nice piece of engineering - one reason nghttp2's HPACK path profiles so flat.
So oghttp2's Huffman decoder must be the problem, right?
That was our assumption going in, and the profiles said no. QUICHE's Huffman kernel is slower than
nghttp2's FSM, but the bulk of the difference sits above the decoder: HttpHeaderBlock and the
layers of representation and bookkeeping each decoded header passes through cost a consistent
20–30 µs per request more than nghttp2's path, on every host we measured. One line item stood
out: the decoder emits symbols through std::string::push_back, one byte at a time, and that call
alone burns 13–20% of all of Envoy's CPU on the x86 hosts in header-saturated runs.
You can see the shape of it in the source. The decoder's hot loop hands every decoded character
to std::string individually:
bool HpackHuffmanDecoder::Decode(absl::string_view input, std::string* output) {
input.remove_prefix(bit_buffer_.AppendBytes(input));
while (true) {
if (bit_buffer_.count() >= 7) {
// Top 7 bits may hold a complete 5-, 6- or 7-bit code.
uint8_t short_code =
bit_buffer_.value() >> (kHuffmanAccumulatorBitCount - 7);
if (short_code < kShortCodeTableSize) {
ShortCodeInfo info = kShortCodeTable[short_code];
bit_buffer_.ConsumeBits(info.length);
output->push_back(static_cast<char>(info.symbol)); // one byte per call
continue;
}
}
// ... longer codes take a second path (PrefixToInfo + a canonical-order
// table) that ends in another output->push_back(c), then the loop refills
// bit_buffer_ from input or returns.
}
}Each push_back is a capacity check and a possible reallocation per byte of header text. Then,
once a value is fully decoded, every header goes through a hash-map lookup plus an arena copy
before Envoy ever sees it:
void HttpHeaderBlock::AppendValueOrAddHeader(const absl::string_view key,
const absl::string_view value) {
value_size_ += value.size();
auto iter = map_.find(key);
if (iter == map_.end()) {
AppendHeader(key, value); // copies key and value into storage_
return;
}
value_size_ += SeparatorForKey(key).size();
iter->second.Append(storage_.Write(value)); // another copy, kept as a fragment
}Both are perfectly reasonable C++ in isolation. On a path that runs once per header field - a few hundred thousand times per second per core - the reallocation checks, map lookups, and copies add up to the 20–30 µs the profiles show - while nghttp2's decoder writes into a caller-provided buffer and moves on.
To be fair, oghttp2's framing and session layer is cheaper than nghttp2's - in the one scenario where header literals stop dominating (realistic headers, direct response, no proxying), oghttp2 wins by 8–13%. The codec isn't slow everywhere. But a proxy's job description is header-heavy, and on header-heavy traffic the plumbing tax buries the framing win.
The fix upstream needs is a leaner path from decoded bytes to header block, which is a deeper refactor than any single hot loop. That's presumably why the Envoy default got flipped back instead of forward.
The fix
For us and our customers, the fix was pleasantly boring:
- Envoy 1.37+: you're done; nghttp2 is the default again.
- Envoy 1.34–1.36: set
envoy.reloadable_features.http2_use_oghttp2: false. It's one line of runtime config and it's worth 15–25% RPS/core on most proxied HTTP/2 traffic.
We rolled the flag across our fleet, the customer's graphs stepped back down, and the calendar invite never came. It is a far, far better thing to flip a runtime flag than to refactor a header pipeline so kudos to the Envoy team for leaving the escape hatch.
Conclusions
Codec defaults are performance changes. A minor-version Envoy bump changed our customer's CPU bill by 20% without touching a single byte on the wire. If you operate proxies, benchmark the versions you ship, not the versions you read about.
Profile before you optimize. We went in certain the Huffman decoder was the villain, and the flamegraphs pointed at string plumbing instead. The decoder was, if anything, the best part of both codecs.
Header decompression is a real workload. A few hundred bytes per request, a dozen header fields each, tens of thousands of requests per second per core, twice per hop - the arithmetic stops being funny quickly.
While we were in there, though, we kept staring at nghttp2's n=4 table and at a 2017 paper by the nghttp2 author and friends that says you can read a whole byte at a time - if you're willing to pay for a table sixteen times larger. Whether that trade survives contact with a real CPU cache is the next post. Stay tuned.
References
- Minimum-redundancy codes - David A. Huffman, "A Method for the Construction of Minimum-Redundancy Codes", Proceedings of the IRE, vol. 40, no. 9, pp. 1098-1101, September 1952. The term paper itself, optimality proof included.
